The
Speed
|
The
NXT is a high performance, handcrafted, molded
carbon fiber, designer kit that went through extensive
wind tunnel testing and computer modeling before
the first carbon fiber mold was made.
All aircraft components are modeled in the computer
and extremely accurate parts are generated from
these models. |
 |
Wind
Galley Model
(Picture by Christopher Webb Films)
|
All the outer mold line tooling was CNC machined,
providing the most precise kit airframe components
produced anywhere. The resulting accuracy allows
the builder to cut exactly on trim lines minimizing
wasted time fitting and re-trimming.
Nemesis Air Racing uses FAA approved FiberCote
E760/carbon fiber pre-preg material and other
aerospace quality material throughout the kit.
We manufacture adjacent parts using Perfect Fit
Technology™ (PFT) and pay attention to every
detail, providing the assembler a quality, fast
building kit.
If you have any questions about the NXT kit,
please contact Collin Boyd at collin@swiftcomposites.co.uk
|
| |
The
Ingredients for Speed
|
|
main NXT components
include the following. Nemesis Air Racing reserves
the right to add any components to or delete
any components from the following list.
-
Wing top and bottom
skins with integral spar caps
-
“Perfect fit”
Split flap skins, right and left
-
Horizontal stabilizer
skins upper/lower
-
Fuselage skins, right
and left, with integral longerons, and low
dielectric vertical stabilizer
-
Webs, closeouts, and
bulkheads with integral rollover structure
-
“Perfect fit”
integral joggled gear doors, access panels
(the air will never know they exist)
-
Motor mount, and accessories
-
Canopy hatch/deck with
integral roll over support
-
Grove Aircraft 500X5.00
Extra Heavy duty wheels brakes and axles,
developed and sized for your NXT
-
Goodyear Flight Custom
tires and tubes
-
Tinted Canopy (optional
tint level)
-
5 Point seat belt harness
systems
-
Rudder pedal system
-
Assembly materials/supplies
including; Construction manual, drawings,
tech support, assembly assistance, carbon
fabric, low dielectric fabric, peel ply,
epoxy resin system, microbaloons, cab-o-sil,
brushes, mix cups, mix sticks, gloves, and
assembly hardware
-
Aileron skins upper/lower,
right and left
-
Elevator skins upper/lower,
right and left
-
Wingtips; upper/lower
right and left
-
Wing, horizontal, vertical
leading edge caps
-
Rudder skins right and
left
-
Fuel Tank, with explosion
resistant foam, valve, cap, and fittings
-
Torso support system
-
Console
-
Instrument panel
-
Steerable tail wheel
(non retractable)
-
Grove Aircraft master
brake cylinders
-
Landing Gear; Struts,
links, fittings, hydraulic actuators, valves,
power pack, and attachment hardware Flap
actuation system, with actuator and hardware
-
Control system hardware,
fittings, bearings, and mountings
-
Canopy latch system,
hingesFuel Gauge
-
Four Tennis Balls
|
Important
Options for the Speed
|
- Lycoming TIO-540-NXT
- Hartzell 3 Blade Propeller
- Engine Baffle System
- Fuel System Option:
Includes 24 volt fuel pump, fuel filter, throttle
mixture bracket, couplings, fittings, hoses,
fire sleeve, cable lock and nuts.
- Oil System:
Includes oil cooler, oil filter, oil filter
mount, hoses, fittings, oil cooler bracket,
plugs, unions, fire sleeve and adapters.
|
|
|
| FREE
4 TENNIS BALLS! |
In the price we include
a set of 4 tennis balls to protect your
wingtip!!!
|
|
